Linux Virtual Machine via Azure CLI: Nginx & TCP Port Setup


In this quick guide, I demonstrate how to deploy a Linux virtual machine (VM) on Azure using the Azure CLI, install an Nginx Web Server, and open port 80. Azure resources can be provisioned and managed via the Azure Portal and Azure CLI, either directly from the command line or using scripts and PowerShell cmdlets. We’ll be installing the most recent Ubuntu LTS image in this guide. At the end of this guide, you will be able to install the NGINX web server, establish an SSH connection to the VM, and start using it just as you would use it in real-life scenarios.

The Azure Cloud Shell, according to Microsoft, is a free interactive shell that you can use to run the steps to create and manage resources on Azure. It has common Azure tools preinstalled and configured for use with your account. Azure CLI can be assessed by clicking on the Cloud Shell icon on the Azure Portal from the upper right corner of the screen. Alternatively, you can also open Cloud Shell in a separate browser tab by going to

If you prefer to install and use the CLI locally, you can also do so by downloading and installing Azure CLI version 2.0.30 or later. Run az --version to find the new version. If you need to install or upgrade, see Install Azure CLI. You can also learn how to back up an Azure VM from the VM settings, remove Azure VM: How to delete a Virtual Machine via the Azure Portal, how to Add or Remove Network Interface from a VM in Azure, how To Configure VM Update Management on Azure Stack Hub.

Create Azure Linux Virtual Machine Using Azure CLI

To get started with creating your first Linux VM with Azure CLI, sign into Azure Portal. Note: to be able to create a Linux Virtual Machine on Azure, you must have an active subscription. If you don’t have one, you can sign up for an Azure free trial account here.

After logging into the portal, the first step is to create the Azure Resource Group—a logical container for deploying and managing resources. In our example here we create a resource group named techdirecharchiveRG in the westus location using the CLI command below:

az group create --name techdirectarchiveRG --location westus
Creating an Azure Resource Group

Now, let’s proceed to create the Linux Virtual Machine. Still, on the same Cloud Shell window, type the command below:

avm create --name techdirectvm --resource-group techdirectarchiveRG --location westus --image UbuntuLTS --admin-user azureuser --generate-ssh-keys
Creating an Azure VM

Installing the Nginx Web Server Linux Virtual Machine

Next, to make good use of the Linux Virtual Machine we just created, we need to install the NGINX web server. To do this we need to update the package sources first and install the Nginx web server. To do this, run the below command:

az vm run-command invoke -g techdirectarchiveRG -n techdirectvm --command-id RunShellScript
--scripts "sudo apt-get update && sudo apt-get install -y nginx"
Package Sources updated and Installed Nginx Web Server

Opening Port 80

The last step in this series is to open the TCP port 80 for web traffic to and from our web server. When provisioning a Linux Virtual Machine in Azure for the first time, it only opens SSH connections by default. Open TCP port 80 with the command az vm open-port to use with the NGINX web server:

az vm open-port --port 80 --resource-group techdirectarchiveRG --name techdirectvm
Opening TCP Port 80

Accessing the Web Server via Web Browser Linux Virtual Machine

Now you can browse to the NGINX default welcome page using any of your preferred web browsers. Visit the Linux VM overview page, copy the public IP for using it as the website address.

The overview page of an Azure VM

The default NGINX website is displayed as shown in the screenshot below:

Nginx Web Server Default Page

I hope you found this blog post helpful. Please let me know in the comment session if you have any questions.
